Outdoor Rotating Triangular Prisms Trivision Billboard

Outdoor Rotating Triangular Prisms Trivision Billboard can show 3 images, vertical or horizontal type. And it have many flipping way for option, such as curtain-open type, curtain-close type..
Trivision billboard can be installed in my places, such as wall, big pole, bridge; size can be customized, standard size normally is 4x3m, 6x3m,12x3m or 18x6m, etc. When the billboard flips, it has excellent visual effect.
The main material is Aluminum alloy frame and tri-angle prisms, Panasonic motor and Crouzet controller,Dupont engineering plastic parts,etc. It is a very economic but hgih-effetive promotion way.

Model:
UNA-131
Brand:
UNA
Code:
8310000000

Availability:

Product Description

Aluminium Triangle Prisma Billboard with LED flood lighting

PRODUCT SPECIFICATION:

Standard Size: 4x3m, 6x3m, 12x3m, 18x6m, Customized sizes are welcome
Prism size: Width:131mm, Thickness: 1.35mm,1.5mm,1.6mm
Frame size: Width:145 x Thickness:160mm
Frame color: Silver, Black, White or customized
Main material: Aluminum alloy
Motor: Original Panasonic motor, 90W/pcs
Controller: Crouzet Brand of Siemens
Poster material:Adhesive vinyl sticker
Power supply: AC220v, Current:0.54A, frequency:50HZ, Power:90W
Gross Weight: 18kg per sqm
Usage: Outdoor, IP55 water-proof and weather-proof
Extra function: With matching LED spot light; Solar system(include solar panel and battery, optional)
Application: Airport,bus-stop,station,chain store,shopping mall,lift,street,T pattern pole,building,supermarket, hotel, restaurant,bank,exhibition hall,highway, etc.

PRODUCT FEATURES:

Anti-rust, Anti-corrosion, Shock resistance, heat radiation
Water-proof & dust-proof, weather-proof, wind resistance of 10 class/level
Easy pictures changing, can display three pictures on each tri-vision billboard
One-year guarantee, arrange on-site installation guide engineer according to customers needs
Image combination: triangular prism 8m without joint for height, and no length limit
Image flipping time: each face 6-12 seconds (preset )
Image stop time: freely set from 1-900 seconds
Qualified installation will ensure normal service life up to 10 years based on 16h/day
