Outdoor self-adhesive sticker advertising Tri-vision Prisma Billboard

Outdoor self-adhesive sticker advertising Tri-vision Prisma Billboard showing 3 advertising images, vertical or horizontal type.
Wall-mounted or pole support; size can be customized, standard size normally is 4x3m, 6x3m,12x3m or 18x6m, etc.
The main material is Aluminum alloy frame and tri-angle prisms, Panasonic motor and Crouzet controller,Dupont engineering plastic parts,etc.
  • UNA-131
  • UNA
  • 8310000000
Availability:

Product Description

Outdoor self-adhesive sticker advertising Tri-vision Prisma Billboard

PRODUCT SPECIFICATION:

  • Standard Size: 4x3m, 6x3m, 12x3m, 18x6m, Customized sizes are welcome

  • Prism size: W:131mm, T: 1.35/1.5/1.6mm

  • Frame size: W:145 x T:160mm

  • Frame color: Silver, Black, White or customized

  • Main material: Aluminum alloy

  • Motor: Original Panasonic motor, 90W/pcs

  • Controller: Crouzet Brand of Siemens

  • Poster material:Adhesive vinyl sticker

  • Power supply: AC220v, Current:0.54A, frequency:50HZ, Power:90W

  • Gross Weight: 18kg per sqm

  • Usage: Outdoor, IP55 water-proof and weather-proof

  • Extra function: With matching LED spot light; Solar system(include solar panel and battery, optional)

  • Application: Airport,bus-stop,station,chain store,shopping mall,lift,street,T pattern pole,building,supermarket, hotel, restaurant,bank,exhibition hall,highway, etc.


PRODUCT FEATURES:

  • Anti-rust, Anti-corrosion, Shock resistance, heat radiation

  • Water-proof & dust-proof, weather-proof, wind resistance of 10 class/level

  • Easy pictures changing, can display three pictures on each tri-vision billboard

  • One-year guarantee, arrange on-site installation guide engineer according to customers needs

  • Image combination: triangular prism 8m without joint for height, and no length limit

  • Image flipping time: each face 6-12 seconds (preset )

  • Image stop time: freely set from 1-900 seconds

  • Qualified installation will ensure normal service life up to 10 years based on 16h/day
